Reference: TEC1-12706

Cooler Peltier Module TEC1-12706 – Thermoelectric, Thermomodule 12V 6A

Name: Cooler Peltier Module TEC1-12706 – Thermoelectric, Thermomodule 12V 6A
Brand: P.U.H. HESTA
SKU: TEC1-12706
Price: 10.8 USD
Availability: InStock

$10.80

Tax included

Peltier Module TEC1-12706 - max 91,2W - Thermoelectric - cooler - 40x40x3,9; 53,3W; 12V; max 6A. Cooling components are used for example in portable car fridges, wine and beer coolers, CPU. Thermomodule, heat pump, to heating, keep the temperature, Generator, transform electricity into temperature. Liquid Component Cooling, Food and Beverage Refrigeration, Commercial Portable Cooling, Medical

Volume discounts

Quantity	Unit discount	You Save
5	$0.27	$1.35
10	$0.54	$5.40

Quantity

Description
Product Details

Thermoelectric Cooler (Peltier Module) - TEC1-12706

Size: 40x40x3.9mm (WxDxH)

Peltier Modules are suitable for the following applications in portable car fridges, coolers, wine and beer coolers.

More information for example on Peltier.pl

It is common in mini tourist fridges for 12V/230V.

Power max	91,2W
Refrigeration power Qcmax	53,3W
Current	4,5A (max 6A)
Voltage	12V (max 15,4V)
Resistance	1,9 - 2,2 Ohm
Length of cables	15cm
Delta Tmax	59°C
Temperature min.	-135°C
Durability (h)	200 000

Using more cells "one on another" ("hot" side together with "cold" of another cell) it increases efficiency of module, with minimum energy loss.

We offer: TEC1-12706

Modules are protected with silicon sealed. In additional, you can use THERMALLY CONDUCTIVE on radiator.

Reference TEC1-12706

In stock 50 Items
